LEFT SIDE ASSEMBLY LEGEND
ITEM NO.
QTY.
PART NO.
DESCRIPTION
1
1
7535101
WLDMT, MTLC, LEFT SIDE
2
2
3239901
BEARING, 2 HOLE FLANGE, 1" ID
3
4
3239311
1/2-13 X 2.75 UNS HEX FHB G5 ZN
4
6
7434001
WASHER, MTS, HAMMER HEAD
5
9
3102801
NUT, NYLOCK 1/2-13 ST ZN
6
2
7477401
CAP. END, 1-1/2 X 3, 11GA SGRY
7
3
7594601
PULLEY, MTS, 3" BELT
8
1
7464701
ASSY, MTS, 150 LB STACK
9
2
7352101
CUSHION, WEIGHT STACK
10
2
7328613
GUIDE ROD, .75 OD SOLID 43.25
11
2
3102806
NUT, NYLOCK 1/4-20 ZN
12
2
3242701
CAP, END, .75 X .50. RD, BLACK
13
8
3239505
WSH, .500 IN-D ST ZN
14
3
3239313
1/2-13 X 3.25 UNS HEX FHB G5 ZN
15
4
3223302
3/8-16 X 1.25 HEX HEAD BOLT
16
1
7459901
ASSY, MTS, INCREMENT WEIGHT
17
2
7465104
SHROUD, MTS, SIDE 44.63" SGRY
18
1
7435605
PANEL, MTS, PLASTIC 44.63"
19
1
3239303
1/2-13 X .75 UNS HEX FHB G5 ZN
20
1
3239305
1/2-13 X 1.25 UNS HEX FHB G5 ZN
21
2
3239316
1/2-13 X 4.00 UNS HEX FHB G5 ZN
22
3
3102507
WASHER, TYPE A PLAIN
23
1
7435101
SHAFT, 3/8" DIA SS, BELT WRAP
24
4
3239503
WSH, .375 IN-D ST ZN
25
1
7434895
WLDMT, MTS, BELT ATTACH
26
1
7435295
PLATE, MTS, BELT CLAMP
27
2
3102807
NUT, NYLOCK 3/8-16 LOW HT
28
2
3103301
SHAFT COLLAR, 3/4 I.D. ZINC
29
2
0017-00101-1587
SHIELD RIVET
30
1
7435701
BELT, SPOOLED, W15/16, T.09
31
1
7422003
LABEL, MOVING PARTS
32
1
7422004
LABEL, 2" ASTM WARN
33
1
M051-00294-A000 WEIGHT STACK NUMBER STRIP
34
1
M051-00298-A000 INCREMENT WT. DECAL (LEFT)
35
1
M051-00289-A000 HAMMER STRENGTH NAME PLATE
36
1
7538501
ASSY, MTLC, ARM LEFT
37
1
7538601
ASSY, MTLC, CAM LEFT
38
1
7488701
LABEL, AXIS OF ROTATION
39
2
7564101
LABEL, MTS, .625 DIA HOLE COVER
40
1
7564501
PIN, FZ/PS, WEIGHT PLATE
41
1
3243901
RING, BRE M11, ST, PP
MTSLC LEG CURL
