MTSLC LEG CURL
SEAT FRAME ASSEMBLY LEGEND ________________________________________
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7537701 WLDMT, MTLC, SEAT FRAME
2 4 3247701 M4 X .7 HXS NO CUP ST BO
3 2 7352001 BUMPER, 2-1/8 X 4-5/8
4 2 7662902 CAP, GRIP 1.50 OD
5 2 3235802 MTLC GRIP, SHADOW GRAY, 11.25"
6 4 3102507 WASHER, TYPE A PLAIN
7 4 3239306 1/2-13 X 1.50 UNS HEX FHB G5 ZN
8 4 3102804 NUT, NYLOCK-JAM 1/2-13 ST ZN
9 1 7564301 SEATRACK, ROLLER SERRATED
10 1 7564401 SEATRACK, FLAT
11 1 3238312 M10x1.5x75mm
12 1 3236210 SCREW, M10 X1.5 65MM
13 1 3236801 NUT, M10 HEX NYLOCK SS
14 1 7422002 LABEL, SEAT ADJUST
15 1 7570601 STOP, ROLLER SEAT
16 1 3235802 GRIP, SHADOW GRAY, 1.5"
