LevelOne 10/100M 32bit Fast Ethernet PC card User Manual
Page 8
LevelOne Fast Ethernet PC Card user’s manual
6
Please take note that the hardkey of a CardBus card is different
from that of the traditional 16-bit PCMCIA card. This mechanism
can protect the 3.3V CardBus card from mis-insertion to 5V 16-bit
PCMCIA slot.
Hardkey of 5/3.3V Traditional PCMCIA Card (left) and 3.3V CardBus
Card (right)
Inserting the LevelOne 10/100Mbps 32bit Fast
Ethernet PC Card
Note!
These instructions apply to most notebook computers.
For detailed information on inserting PC cards into your
notebook, consult the notebook user’s manual.
RJ-45
Status LEDs
