General venting
14
Installation & Operation Manual
Figure 3-1 Two-Pipe Sidewall Termination - See page
22 for more details Figure 3-2 PVC/CPVC Concentric Sidewall
Termination - See page 26 for more details
Direct venting options - Sidewall Vent
Figure 3-3 Two-Pipe Vertical
Termination - See page 29 for
more details Figure 3-4 PVC/CPVC Concentric
Vertical Termination - See page 30
for more details Figure 3-5 Vertical Vent, Sidewall Air
- See page 18 for more details
