8

STEP 4:

FIGURE 4

• LOOSELY assemble each UPRIGHT (1) to the UPRIGHT BASE (2) using four 1/2 X 4” BOLTS (9), eight 1/2” WASHERS (10),

and four 1/2” LOCK NUTS (11). See FIGURE 4.

• LOOSELY assemble the UPPER CONNECTOR (7) using four 1/2 X 3” BOLTS (8), four 1/2” WASHERS (10), and two 1/2”

LOCK NUTS (11). See FIGURE 4.

0

1

2

3

4

5

6

1/2

1/2

1/2

1/2

1/2

1/2

11

2

1

10

10

7

11

1/2 X 3” 8

1/2 X 4” 9
