5
PARTS LIST
PART #
LEA6641509
LEA6641810
LEA6605710
LEA6605810
LEA6605910
LEA6606010
LEA6658610
LEA3235312
KEY
1
2
3
4
5
6
7
8
QTY
2
2
2
2
1
1
1
12
PART #
LEA3235316
LEA3114401
LEA3114701
LEA6606801
LEA6405201
LEA7234801
LEA6590801
D E S C R I P T I O N
1/2 X 4” BOLT
1/2” WASHER
1/2” LOCK NUT
SPRING PIN ASSEMBLY
2” SQ. END CAP
2” SQ. COVER CAP
3 X 2” INSERT GUIDE
QTY
4
20
14
6
4
4
12
DESCRIPTION
UPRIGHT
UPRIGHT BASE
SAFETY RAIL
BAR SUPPORT
CHIN BAR
LOWER CONNECTOR
UPPER CONNECTOR
1/2 X 3” BOLT
KEY
9
10
11
12
13
14
15
FIGURE 1
STEP 1:
• Slide four 2” SQ. COVER CAPS (14) over the ends of each UPRIGHT BASE (2) as shown in FIGURE 1.
• LOOSELY assemble the LOWER CONNECTOR (6) between each UPRIGHT BASE (2) using four 1/2 X 3” BOLTS (8), four 1/2”
WASHERS (10), and four 1/2” LOCK NUTS (11). See FIGURE 1.
6
1/2 X 3” 8
2
14
10
11
