STEP 3:

FIGURE 3

• SECURELY assemble the SMART RACKS (3) to the outside of the UPRIGHT FRAMES (1) as shown in FIGURE 3, using six 1/2 X 3”

BOLTS (6), six 1/2” WASHERS (7), and six 1/2” LOCK NUTS (8).

Thank you for purchasing the Parabody 838 POWER SYSTEM. If unsure of proper use of equipment, call
your local Parabody distributor or call the Parabody customer service department at (800) 328-9714.

6 1/2 X 3”
