Page 9
3
If possible, route the unit’s power cable and transducer cable away from
other wiring. VHF radio antenna cables radiate noise when transmitting,
so be certain to keep the sonar’s wires away from it. You may need to
route the sonar unit’s power cable directly to the battery to isolate it from
other wiring on the boat.
CABLE CONNECTIONS - GlobalMap 1600 Only
RED
(+12
VDC)
BLACK
(GROUND)
GREEN
(NMEA
RECEIVE)
ANTENNA
WHITE
(NMEA
TRANSMIT)
LOWRANCE
