A-2 INSTALLATION
BIG RED™ 600
A-2
SAFETY PRECAUTION
Read this entire installation section before you start
installation.
LOCATION AND VENTILATION
The welder should be located to provide an unrestrict-
ed flow of clean, cool air to the cooling air inlets and to
avoid restricting the cooling air outlets. Also, locate the
welder so that the engine exhaust fumes are properly
vented to an outside area.
STORING
1. Store the machine in a cool, dry place when it is
not in use. Protect it from dust and dirt. Keep it
where it can’t be accidentally damaged from con-
struction activities, moving vehicles, and other
hazards.
2. Drain the engine oil and refill with fresh 10W30
oil. Run the engine for about five minutes to cir-
culate oil to all the parts. See the MAINTE-
NANCE section of this manual for details on
changing oil.
3. Remove the battery, recharge it, and adjust the
electrolyte level. Store the battery in a dry, dark
place.
STACKING
BIG RED™ 600 machines cannot be stacked.
ELECTRIC SHOCK can kill.
• Do not touch electrically live parts or
electrode with skin or wet clothing.
• Insulate yourself from work and
ground
• Always wear dry insulating gloves.
------------------------------------------------------------------------
ENGINE EXHAUST can kill.
• Use in open, well ventilated areas or
vent exhaust outside.
------------------------------------------------------------------------
MOVING PARTS can injure.
• Do not operate with doors open or
guards off.
• Stop engine before servicing.
• Keep away from moving parts.
------------------------------------------------------------------------
See additional warning information at
front of this operator’s manual.
WARNING
ANGLE OF OPERATION
To achieve optimum engine performance the BIG
RED™ 600 should be run in a level position. The
maximum angle of operation for the Deutz engine is
30 degrees fore and aft, 40 degrees right and 45
degrees left. If the engine is to be operated at an
angle, provisions must be made for checking and
maintaining the oil level at the normal (FULL) oil
capacity in the crankcase. When operating the welder
at an angle, the effective fuel capacity will be slightly
less than the amount specified.
LIFTING
The BIG RED™ 600 weighs approximately 1772lbs.
(804kg.) with a full tank of fuel 1657lbs.(752kg) less
fuel. A lift bail is mounted to the machine and should
always be used when lifting the machine.
HIGH ALTITUDE OPERATION
At higher altitudes, output derating may be necessary.
For maximum rating, derate the welder output 5% for
every 300 meters (984 ft.) above 1500 meters (4920
ft.). For output of 500A and below, derate the welder
output 5% for every 300 meters (984 ft.) above 2100
meters (6888 ft.).
Contact a Deutz Service Representative for any
engine adjustments that may be required.
HIGH TEMPERATURE OPERATION
WELDER OUTPUT RATINGS AT
TEMPERATURES ABOVE 40°C
AMPS DUTY CYCLE VOLTS TEMPERATURE
450 DC 30% 38 55°C
500 DC 30% 40 50°C
550 DC 30% 34 45°C
• Lift only with equipment of ade-
quate lifting capacity.
• Be sure machine is stable when lift-
ing.
• Do not lift this machine using lift
bail if it is equipped with a heavy
accessory such as trailer or gas
cylinder.
FALLING • Do not lift machine if lift bail is
EQUIPMENT can damaged.
cause injury. • Do not operate machine while
suspended from lift bail.
--------------------------------------------------------------------------------
WARNING
