PRODUCT DATA
BUSINESS SERIES
Features
8 - 10/100 Switched RJ-45
ports deliver up to 200Mbps
of throughput per port
1 - MiniGBIC Port
1 - 100BASE-LX uplink port
with LC type connector and
built-in transceiver
3.8 Gbps, non-blocking,
store-and-forward switching
mechanism
Simplified QoS management
enabled by advanced
queuing techniques using
802.1p, Diffserv or ToS traffic
prioritization specifications
Configuration and
monitoring from a standard
web browser with WebView
management
Secure remote management
of the switch via SSH and
SSL secure channel network
protocols
802.1Q based VLANs enable
segmentation of networks
for improved performance
and security
Private VLAN Edge for
simplified network isolation
for guests connections or
autonomous networks
Automatic configuration
of VLANs across multiple
switches through
GVRP/GARP
Automatic MDI/MDIX
detection support
User/Network port
level security via 802.1X
authentication and
MAC-based filtering
•
•
•
•
•
•
•
•
•
•
•
•
8-Port 10/100 Ethernet Switch
with WebView and 100BASE-LX Uplink
Specifications
Model SRW208L
Ports 8 RJ-45 connectors for 10/100BASE-TX, 1 miniGBIC/SFP port,
and 1 LC type connector for 100Base-LX SMF port at 1310nm
Console port
Auto MDI/MDI-X
Auto-negotiate/manual setting
Cabling Type UTP CAT 5 or better for 10BASE-T/100BASE-TX,
UTP CAT 5e or better for 1000BASE-T
LEDs 10/100 Link/Act, 1 Gig Link/Act, Speed, 1 100LC Link/Act, System
Performance
Switching Capacity 3.8 Gbps, non-blocking
Forwarding Rate 2.8 Mpps wire-speed performance
Layer 2
MAC table size 8K
Number of VLANs 256 active VLANs (4096 range)
VLAN Port-based and 802.1Q Tag-based VLANs
Management VLAN
HOL Blocking Head of line blocking prevention
Management
Web User Interface Built-in Web UI for easy browser-based configuration (HTTP/HTTPS)
SNMP SNMP version 1, 2c, 3 with support for traps
SNMP MIBs RFC1213 MIB-2, RFC2863 Interface MIB, RFC2665 Ether-like MIB,
RFC1493 Bridge MIB, RFC2674 Extended Bridge MIB (P-bridge, Q-bridge),
RFC2819 RMON MIB (groups 1,2,3,9 only), RFC2737 Entity MIB,
RFC 2618 RADIUS Client MIB RFC 1215 Traps
RMON Embedded Remote Monitoring (RMON) software agent supports four
RMON groups (history, statistics, alarms, and events) for enhanced traffic
management, monitoring, and analysis.
Firmware Upgrade Web browser upgrade (HTTP) and TFTP
Port Mirroring Traffic on a port can be mirrored to another port for analysis with
a network analyzer or RMON probe.
Other Management Traceroute
Secure Socket Layer (SSL)
Secure Shell (SSH)
RADIUS
Port mirroring
TFTP upgrade
SSL security for Web UI
DHCP client
BootP
SNTP
Xmodem upgrade
Cable diagnostics
PING
Telnet client (SSH secure support)
Security
IEEE 802.1X 802.1X - RADIUS Authentication. MD5 Encryption
Access Control ACLs - Drop or Rate Limit based on:
Source and destination MAC-based
Source and destination IP address
Protocol
TOS/DSCP
Port
VLAN
Ethertype
