Page 32: Maintenance
D-4
MAINTENANCE
D-4
POWER MIG 255C
TABLE D.2
ACCESSORIES AND EXPENDABLE REPLACE-
MENT PARTS FOR MAGNUM 250L GUN AND
CABLE ASSEMBLIES
English
Metric
Description
Part No.
Size
Size
CABLE LINER
For 15'
KP1934-2
.025 – .030"
0.6 – 0.8 mm
(4.5 m) or
KP1934-1
.035 – .045"
0.9 – 1.2 mm
shorter cable
KP1955-1
3/64"
1.2 mm
(Alum. wire)
(Alum. wire)
CONTACTS TIPS
Standard Duty
KP2020-6B1
.025"
0.6 mm
KP2020-7B1
.030"
0.8 mm
KP2020-1B1*
.035"
0.9 mm
KP2020-2B1*
.045"
1.2 mm
Heavy Duty
KP2021-1B1
.035"
0.9 mm
KP2021-2B1
.045"
1.2 mm
Tapered
KP2021-5B1
.025"
0.6 mm
KP2021-6B1
.030"
0.8 mm
KP2022-1B1
.035"
0.9 mm
KP2022-2B1
.045"
1.2 mm
Notched (For Alum.)
KP2010-5B1
3/64"
1.2 mm
(Alum. Wire)
(Alum. Wire.)
GAS NOZZLES
Fixed (Flush)
KP1931-1
3/8"
9.5 mm
KP1931-2*
1/2"
12.7 mm
KP1931-3
5/8"
15.9 mm
Fixed
(Recessed)
KP1930-1
3/8"
9.5 mm
KP1930-2
1/2"
12.7 mm
KP1930-3
5/8"
15.9 mm
Requires: Gas
Diffuser as’bly
KP2026-3 *
.025 – .045"
0.6 – 1.2 mm
Adjustable Slip On KP1935-2
1/2"
12.7 mm
KP1935-1
5/8"
15.9 mm
Requires:
Nozzle Insulator
KP2025-1
Requires:
Gas diffuser
KP2026-2
.025 – .030"
0.6 – 0.8 mm
As’bly
KP2026-1
.035 – .045"
0.9 – 1.2 mm
Gasless nozzle
KP1947-1
∆
(For Innershield)
GUN TUBE ASSEMBLIES
Standard (60°)
KP2015-1 *
45°
KP2041-1
*Included with POWER MIG 255C
Requires KP2026-1 Gas Diffuser
