POWER MIG 255C
SVM170-A
October, 2006
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However,
your overall safety can be
increased by proper installation
. . . and thoughtful operation on
your part. DO NOT INSTALL,
OPERATE OR REPAIR THIS
EQUIPMENT WITHOUT READ-
ING THIS MANUAL AND THE
SAFETY PRECAUTIONS CON-
TAINED THROUGHOUT. And,
most importantly, think before
you act and be careful.
SERVICE MANUAL
For use with machines having Code Number : 11192, 11218
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
• World's Leader in Welding and Cutting Products •
Copyright © 2006 Lincoln Global Inc.
RETURN TO MAIN MENU
Document Outline
- Master Table of Contents
- Safety Section
- Section A - Installation
- Section B - Operation
- Section C - Accessories
- Section D - Maintenance
- Section E - Theory of Operation
- Section F - Troubleshooting and Repair
- Symptoms
- Major Physical or Electrical Damage is Evident
- Machine is dead — no open circuit voltage output and no wire feed when gun trigger is pulled. The machine display may be lit.
- No open circuit voltage output but wire feeds normally when gun trigger is pulled.
- Wire feeds but welding output is low causing wire to “stub”. Welds are “cold”. Machine cannot obtain full rated output of 200 amps at 28 volts.
- The output voltage and wire feed is present continuously or pulsing when gun trigger is NOT activated.
- The output voltage is present continuously when gun trigger is NOT activated.
- No control of arc voltage. Wire feeding is normal.
- There is no gas flow when gun trigger is pulled. Wire feeds and weld voltage is present.
- The machine stops feeding wire while welding.
- No control of wire feed speed. Other machine functions are normal
- There is no wire feed when gun trigger is pulled. Normal open circuit voltage is present.
- The arc is unstable and or “hunting”.
- Weld bead is narrow or ropy. May have porosity with electrode stubbing into plate.
- The contact tip seizes in the gas diffuser.
- The welding arc is variable and sluggish.
- The arc striking is poor.
- Section G - Electrical Diagrams
