La Crosse Technology WS-1613-IT - Manual

PROFESSIONAL WEATHER CENTER
WS-1613-IT
Operation Manual
IMPORTANT:
When a battery change is required on any of the units of this set, ALL units
have to be reset and user must go through initial set-up steps again.
1
Table of Contents
Topic Page
Features 3
Setting up 6
Function keys 12
LCD Screen 14
Manual Setting 16
Time alarm setting 24
Weather alarm operations 25
Hysteresis 31
Weather forecast and weather tendency 32
Wind direction and wind speed measurement 36
Rainfall measurement 37
Viewing history data 37
Viewing the min/ max weather data 39
Switch On/ Off buzzer 46
Outdoor transmission 915 MHz reception 48
Positioning 49
Care and Maintenance 53
Specification 54
Warranty Info 56
2
PROFESSIONAL WEATHER CENTER
Instruction Manual
Congratulations on purchasing this state-of-the-art Professional Weather Center as an
example of excellent design and innovative technology. Featuring time, date,
calendar, weather forecast, wind direction and speed, rainfall, outdoor temperature
and outdoor humidity, air pressure and various alarm settings for different weather
conditions, this Weather Center will provide you with extensive weather information
and forecast.
INSTANT TRANSMISSION is the
state-of-the-art new wireless
transmission technology, exclusively
designed and developed by LA
CROSSE TECHNOLOGY. INSTANT
TRANSMISSION
offers you an
immediate update (every 4 seconds!)
of all your outdoor data measured
from the transmitters: follow your
climatic variations in real-time!
This product offers:
3
FEATURES:
Weather Center
• Time display (manual setting)
• 12/24 hour time display
• Calendar display (weekday, date, month, year)
• Time alarm function
• Weather forecasting function with 3 weather icons and weather tendency
indicator
• Outdoor temperature display in ºF/°C
• Outdoor Humidity display as RH%
• MIN/MAX value of outdoor temperature and humidity display with time & date of
recording
Function keys
LCD
Foldout stand
Battery compartment
cover
Hanging hole
4
• Low/High outdoor temperature and humidity alarm
• Relative air pressure displayed in inHg or hPa
• Air pressure tendency indicator for the past 12 hours (bargraph format)
• LCD contrast selectable
• Low battery indicator
• Wind direction displayed in 16 steps
• Wind speed displayed in mph, km/h, or m/s, and Beaufort scale
• Wind chill displayed in F of C
• Max wind speed displayed with time & date of recording
• High alarm function for wind speed
• Manual reset of outdoor temperature/ humidity, pressure and wind chill data
• Total rainfall displayed in mm or inch
• Storm warning alarm
• Buzzer on/off selectable
• Storage of 200 sets of history weather data recorded in 3-hour intervals
• Wireless transmission at 915 MHz
• Transmission range up to 330 feet (100 meters)
Thermo-hygro Sensor
• Remote transmission of the outdoor temperature and humidity
to the Weather Center at 915 MHz
• Weather-resistant casing
• Wall mounting case (to be mounted in a sheltered place. Avoid
direct rain and sunshine)
5
Wind Sensor
• Connected to the thermo-hygro sensor by cable
• Can be installed onto a mast or a horizontal panel
Rain Sensor
• Connected to the thermo-hygro sensor by cable
• To be mounted onto a horizontal panel
