Parameter table B - Water Heater Operation
(continued)
Table 1E_(continued from previous page) This table lists SMART SYSTEM control module parameters and where to
access them for water heater operation ONLY
Menu
Sub
Item
Description
See
Page
User Access
Installer Access
Display Modify Display Modify
I
1
BMS Type
23
No
No
Yes
Yes
2
Voltage at Minimum (V at Min)
23
No
No
Yes
Yes
3
Voltage at Maximum (V at Max)
23
No
No
Yes
Yes
4
Minimum Power (Min Power)
23
No
No
Yes
Yes
5
Maximum Power (Max Power)
23
No
No
Yes
Yes
6
Minimum Setpoint (Min Setpoint)
23
No
No
Yes
Yes
7
Maximum Setpoint (Max Setpoint)
24
No
No
Yes
Yes
8
Voltage to Start CFH (V at Start)
24
No
No
Yes
Yes
9
Voltage Differential Stop CFH (V Diff Stop)
24
No
No
Yes
Yes
J
1
DHW Pump Delay (DHW Pump Dlay)
24
No
No
Yes
Yes
K
1
Service Interval Time (months) (Srv Int Time)
24
No
No
Yes
Yes
2
Service Interval Run (Srv Int Run)
24
No
No
Yes
Yes
3
Service Interval Operation (hours) (Srv Int Op)
24
No
No
Yes
Yes
4
Reset Service
24
No
No
Yes
Yes
5
Accept Personality Plug (Accept PPlug)
24
No
No
Yes
Yes
