PC3500TX Terminal Installation & User’s Guide - 21
A P P E N D I X A
Install/Replace the Optional Backup
Battery
♦ Unlock and remove the terminal from its mounting plate and set aside
♦ Remove the phillips head screw from the battery holder located in the mounting
plate
♦ Remove the old battery
♦ Place the new battery into the battery compartment
♦ Replace the battery holder
♦ Plug the battery connector into the socket located to the right of the power
connection in the back of your terminal
♦ Replace the terminal onto its mounting plate and lock into place
