Link electronic MC-6 User Manual
Page 31
31
MC
MC--6 Multi
6 Multi--Channel Power Amplifier Specifications
Channel Power Amplifier Specifications
Power Output per Channel:
Power Output per Channel:
Continuous RMS watts Monoblock: Two-Channel: Six-Channel:
@8 ohms 330 watts 250 watts 150 watts
@4 ohms 600 watts 400 watts 250 watts
Power Bandwidth:
Power Bandwidth:
0.1 Hz to 160 kHz, -3 dB
Slew Rate:
Slew Rate:
25 volts/microsecond
THD + Noise:
THD + Noise:
Less than 0.01% at Rated Power
Damping Factor:
Damping Factor:
>60, Channels 1 and 6
>40, Channels 2 through 5
Gain (1 watt, 8 ohms):
Gain (1 watt, 8 ohms):
26 dB, 141 mV
Input Impedan
Input Impedance:
ce:
36k ohms per Channel
Common Mode
Common Mode
Rejection Ratio:
Rejection Ratio:
>75 dB, 20 – 20 kHz
Absolute Phase:
Absolute Phase:
Phase-Inverted
Output Current:
Output Current:
60 amps peak, Channels 1 and 6
30 amps peak, Channels 2 – 5
Linked channels are cumulative
Power Consump
Power Consumption:
tion:
40 Watts Standby, 200 Watts Idle,
1200 Watts Maximum
Inputs:
Inputs:
User Selectable,
6 x Balanced XLR
6 x Unbalanced RCA
Outputs:
Outputs:
Six Pairs Five-Way Binding Posts
Amplifier Dimensions:
Amplifier Dimensions:
17.5” W x 22” D x 11.4” H
44.5 cm W x 56 cm D x 28.5 cm H
Amplifier Weight:
Amplifier Weight:
124 lbs.
56 kg
Shipping Dimensions:
Shipping Dimensions:
24” W x 22” D x 13” H
61cm W x 56cm D x 33cm H
Shipping Weight:
Shipping Weight:
164 lbs.
75 kg
