To Configure the Amplifier for Two To Configure the Amplifier for Two--Channel Stereo, Vertical Tri Channel Stereo, Vertical Tri--Amplification Use Amplification Use
11 Connect the left channel interconnect from your pre-amp or
source component to the CHANNEL 1 balanced XLR or
unbalanced RCA input connector. Select the correct balanced
or unbalanced input connector by flipping the Channel 1
BAL/UNBAL switch towards the connector that is being used.
22 Connect the right channel interconnect from your pre-amp or
source component to the CHANNEL 6 balanced XLR or
unbalanced RCA input connector. Select the correct balanced
or unbalanced input connector by flipping the Channel 6
BAL/UNBAL switch towards the connector that is being used.
33 Flip the LINK INPUT 2 TO 1/UNLINK (NORMAL) switch “ON”, or up
towards LINK INPUT 2 TO 1. Flip the LINK INPUT 3 TO 2/UNLINK
(NORMAL) switch “ON”, or up towards LINK INPUT 3 TO 2.
44 Flip the LINK INPUT 6 TO 5/UNLINK (NORMAL) switch “ON”, or up
towards LINK INPUT 6 TO 5. Flip the LINK INPUT 5 TO 4/UNLINK
(NORMAL) switch “ON”, or up towards LINK INPUT 5 TO 4.
55 Connect your left woofer loudspeaker cable to the Channel 1
SPEAKER OUTPUT connector. Connect your left midrange
loudspeaker cable to the Channel 2 SPEAKER OUTPUT connector.
Connect your left tweeter loudspeaker cable to the Channel 3
SPEAKER OUTPUT connector.
66 Connect your right woofer loudspeaker cable to the Channel 6
SPEAKER OUTPUT connector. Connect your left midrange
loudspeaker cable to the Channel 5 SPEAKER OUTPUT connector.
Connect your left tweeter loudspeaker cable to the Channel 4
SPEAKER OUTPUT connector.
The signal connections are now complete. Please recheck your
connections before operating the amplifier.
