18

Cable connections, GlobalMap 7500 and GlobalMap 7600.

Power/Data

Network

LGC 2000

GPS Module

NMEA 0183

Data cable

(four wires)

NMEA 2000

Power cable

Power
Supply
wires

25' Y-adapter
extension cable

60-ohm
terminator
