TROUBLESHOOTING & REPAIR
F-42
F-42
POWER MIG 350MP
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Section TOC
MOTOR & GEAR BOX ASSEMBLY
REMOVAL AND REPLACEMENT
(continued)
REPLACEMENT PROCEDURE
1. Bolt the wire drive assembly to the wire drive
compartment.
2. Secure the wire drive compartment to the
divider panel welded assembly.
3. Mount the motor/gearbox assembly to the wire
drive assembly and attach with screws.
4. Assemble the drive roll components to the wire
drive assembly.
5. Attach the flex hose and clamp.
6. Attach the tool tray.
7. Attach the wire gun and wire.
