EXTERNAL
EQ
UIPMENT
SETUP
22
EXTERNAL EQUIPMENT SETUP
DVI to HDMI Connection
RESET
LAN
(SERVICE ONLY)
RGB IN
RGB(PC)
COMPONENT IN
VIDEO
RJP
INTERFACE
AUDIO
AUDIO
(RGB/DVI)
HDMI/DVI IN
2
1(DVI)
L R DVI-DTV OUTPUT L R
1
2
G G A DVI to HDMI cable or adapter is required for this
connection. DVI doesn't support audio, so a separate
audio connection is necessary.
NOTE !
Connect the DVI output of the digital set-top box to
the
H HD DM MII//D DV VII IIN N 1 1 ((D DV VII)) jack on the TV.
Connect the audio output of the digital set-top box to
the
A AU UD DIIO O ((R RG GB B//D DV VII)) jack on the TV.
1. How to connect
2. How to use
■ Turn on the digital set-top box. (Refer to the owner’s man-
ual for the digital set-top box.)
■ Select the H HD DM MII 1 1 input source on the TV using the
IIN NP PU UT T button on the remote control.
2
1
