I ITEM DESCRIPTION
1 Dip Tube WTR1018
2 Anode, Magnesium 3/4" dia. WTR1019
2 Anode, Aluminum 3/4" dia. WTR1040
3 T&P Relief Valve RLV1001
4 Gasket Element GKT2513
5 Brass Drain Valve DRV2508
6 Thermostat Upper All 2&3 wire interlocking TST1119
7 Thermostat Lower TST1120
7 Thermostat Lower All 3 wire & single element TST1122
8 Access Cover JKT1201
I ITEM
WATTAGE 120v 208v 240v 480v
9 1500 ELE1404** - - -
9 1500 ELE1420 ELE1423 ELE1421 -
9 2000 ELE1422 - ELE1423 ELE1424
9 2500 ELE1425 ELE1430 ELE1426 ELE1427
9 3000 - ELE1405 ELE1428 ELE1429
9 3500 - - ELE1430 ELE1431
9 4000 - - ELE1405 ELE1406
9 4500 - ELE1414 ELE1408 ELE1409
9 5000 - ELE1410 ELE1411 ELE1412
9 6000 - ELE1413 ELE1414 ELE1415
May-06
** MT MODELS, 6 3/4 IN LENGTH
MODEL NUMBERS / PART NUMBERS
Please provide model & serial number when ordering parts.
All Residential Electric Models
*OLDER UNITS MAY HAVE FOUR BOLT FLANGE ELEMENTS. PLEASE CONSULT FACTORY FOR PART NUMBER
ELEMENTS : COPPER- SHEATH, TIN COATED, SCREW TYPE*
