A-1
A-1 INSTALLATION
75°C Copper Wire 75°C Copper Wire
Input Ampere in Conduit in Conduit
Input Voltage/ Fuse or Breaker Rating On AWG (IEC) Sizes AWG (IEC) Sizes
(For lengths (For lengths
Frequency (Hz) Size (Super Lag) Nameplate up to 100 ft.) exceeding 100 ft.)
208/50/60 60 36 10 (6 mm 2 ) 8 (10 mm 2 )
230/50/60 60 33 10 (6 mm 2 ) 8 (10 mm 2 )
NOTE: Use #10 AWG Grounding Wire
TECHNICAL SPECIFICATIONS – POWER MIG 200
INPUT – SINGLE PHASE ONLY
RATED OUTPUT
OUTPUT
RECOMMENDED INPUT WIRE AND FUSE SIZES
Height Width Depth Weight
31.79 in 18.88 in 38.78 in 210 Ibs
808 mm 480 mm 985 mm 95 kg
PHYSICAL DIMENSIONS
Wire Speed 50 – 700 IPM (1.27 – 17.8 m/minute)
WIRE SPEED RANGE
Standard Voltage/Frequency Input Current @ 150 Amp Rated Output Input Current @ 150 Amp Rated Output
208/230/50/60 Hz 28/26 Amps 36/33
Duty Cycle Amps Volts at Rated Amperes
30% 200 Amps 22 Volts
40% 180 Amps 23 Volts
60% 150 Amps 24 Volts
Welding Current Range Maximum Open Circuit Voltage Welding Voltage Range
30 – 200 Amps 40 Volts 13.5-22 Volts
POWER MIG 200
