DVBT-C30B

USER MANUAL

7

KNOWING YOUR DVB-T

1 Antenna

8

Speaker

2 LCD panel

9

Battery Connector terminal

3 Power LED

(LED will glow green if

in use)

10 Eyelet for lanyard (Not Supplied)

4 IR Sensor

11 Earphone/Audio out Socket

5 Menu/Exit Button

12 DC power connecter socket

6 OK/Mute button

13 Power ON/OFF Switch

7 Multi Selector (VOL & Channel)

14 External Antenna connector

(Device shown with battery pack removed)
