Chapter 7. Locations
This section provides illustrations to help locate the various connectors, controls and components of the
computer.
Locating components, controls and connectors
The following illustrations will help you to locate the various components, controls and connectors on your
computer.
Front view
The following illustration shows the location of controls and components on the front of the computer.
1. Power button
5. USB ports (2)
2. Hard disk drive indicator
6. Headphone connector
3. Optical drive (selected models only)
7. Microphone connector
4. Memory card reader
