AM/FM and CD Select – In radio mode,
press AM/FM to select AM, FM1 or FM2
frequency bands. In CD mode, press to
stop play and begin radio play. Press CD to
enter CD mode and to play a CD already
in the system.
SAT and SCAN/SHUF – In radio mode,
press SCAN/SHUF to hear a sampling of all
listenable stations. In CD mode, press to hear
a brief sampling of all selections. Press again
to stop at the desired selection. SAT is only
available when equipped with Satellite radio.
Your Audiophile radio may be equipped with
Satellite-ready capability. The kit to enable
Satellite reception is available through your
Lincoln dealer. Detailed Satellite instructions
are included with the dealer-installed kit.
Dealer installed Satellite kit is available only in
the continental United States.
Volume/Power Control – Press the
control to turn the audio system on or off.
Turn the control to raise or lower volume. To
engage speed sensitive volume feature (if
equipped), press MENU and use SEL-TEXT to
adjust the volume setting.
Seek Function – In radio mode, press to
find the next listenable station up or down
the band. In CD mode, press to select the
next/previous track on the current disc.
Press and hold to advance/reverse within
the current track.
TUNE-CAT – In radio mode, press to move
to the next frequency up or down the band.
CAT is only available when equipped with
satellite radio.
Mute Mode – Press to mute the playing
media. Press again to return to the
playing media.
SEL-TEXT – Press to adjust sound output
and distribution after selecting BASS, TREB,
BAL or FADE. TEXT is only available when
equipped with Satellite radio. Your
Audiophile radio may be equipped with
Satellite-ready capability. The kit to enable
Satellite reception is available through your
Lincoln dealer. Detailed Satellite instructions
are included with the dealer-installed kit.
Dealer installed Satellite kit is available only
in the continental United States.
Setting Memory Preset Stations –
Select AM, FM1 or FM2 band, then select a
station. Next, press and hold a control until
the sound returns.
Temperature Selection – To control the
temperature for the driver and for the
passenger, select the desired temperature
by pressing the driver’s or passenger’s
temperature control.
Outside Temperature – Press to display
the outside air temperature. Press again to
disengage.
Fan Speed – To adjust manually, use the
control to raise or lower the fan speed.
Automatic Operation – In addition to
determining A/C on or off, fan speed and
airflow location, it also determines if the
system is to use outside or recirculated air to
heat or cool the interior.
A/C Control – Press to manually enable
or disable the air conditioning. Used in
conjunction with the recirculation control, it
will reduce the amount of time required to
cool the inside of the vehicle.
Dual Operation – Press DUAL to enable
or disable the dual zone temperature
feature.
Manual Override Controls – When
pressed, these five controls will override
automatic operation. All controls allow you
to determine where airflow is directed. To
return to automatic operation, press AUTO.
Auxiliary Radio Controls – Depending
on the mode, press NEXT to select a preset
station or the next track on a disc.
Press VOL + or VOL – to adjust the volume.
Auxiliary Climate Controls
(if equipped) – Press TEMP + or – to adjust
the temperature.
6W1J -19G217- DA
February 2006
First Printing
Quick Reference Guide
Town Car
Litho in U.S.A.
Audiophile AM/FM Satellite Compatible Stereo
In-Dash Six CD Sound System
(if equipped)
C l i m a t e C o n t r o l S y s t e m E l e c t r o n i c M e s s a g e C e n t e r
R e m o t e T r u n k R e l e a s e C o n t r o l
O p t i o n a l S t e e r i n g W h e e l C o n t r o l s
A
F
G
A
B
H
G
F
E
B
C
A
B
C
D
The electronic message center, located on
your instrument cluster, displays important
vehicle information through a constant
monitor of vehicle systems. This system only
works when the ignition is in the ON
position. The message center allows you to
check trip elapsed drive time, monitor the
average fuel economy and instantaneous
fuel economy, check the on/off status of the
air suspension system, and see how many
kilometers/miles you can drive before
running out of fuel. The premium display
severity indicator helps you determine the
nature of the information being displayed:
Red for high severity, Amber for medium
severity and non-lit for information only.
You can select different features for the
message center to display by using the
message center controls located in the
center of the instrument panel. Please refer
to your Owner’s Guide for complete details
on the message center display features.
Setup – Press this control to display SYSTEMS
CHECK, DISPLAY (odometer/speedometer),
TEXT SIZE (normal/large), UNITS
(english/metric), LANGUAGE, COMPASS
ZONE/CALIBRATION, OIL MINDER
START VALUE.
Select – Press this control to select
functions in the SETUP menu.
Info – This control displays the trip odometer,
trip elapsed drive time, distance to empty,
average fuel economy and the instantaneous
fuel economy.
Reset – Press to reset the functions shown
in the INFO and SETUP menus.
D
E
E s s e n t i a l I n f o r m a t i o n
E
H
F
Fuel Tank Capacity – Your vehicle’s fuel tank can accommodate 71.9L (19 gallons) of gasoline.
Your vehicle is designed to use "Regular" unleaded gasoline with a pump (R+M)/2 octane rating of 87
for optimum performance. The use of gasoline with lower octane ratings may degrade performance.
Tire Pressure – Your tire pressure is properly set at the dealership according to the recommended
specifications found on the Safety Compliance Certification Label or Tire Label located on the front
door latch pillar on the driver’s side. Please check your tire pressure during routine maintenance
and seasonal changes.
Warning: Improperly inflated tires can affect vehicle handling and can fail
suddenly, possibly resulting in loss of vehicle control.
Fuses – If electrical components in the vehicle are not working, a fuse may have blown. For more
information about changing the fuse, please consult your Owner’s Guide.
Changing the Tires – If you get a flat tire while driving, do not apply the brake heavily. Instead,
gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on
the side of the road. Your vehicle is equipped with a temporary spare tire. The temporary spare is
designed for emergency use only. Replace this tire with a full-size tire as soon as possible. Also,
be sure to turn OFF the air suspension switch (if equipped) prior to jacking, hoisting, or towing
your vehicle.
Location of the Spare Tire and Tools
Item Location
Temporary Spare At the right-hand side of the trunk,
Tire and Jack in a holder bracket next to the wheel well
Lug Wrench Attached to the jack
Air Suspension Switch In the trunk, on the left side
Roadside Emergencies – To fully assist you if you should have a vehicle concern, Lincoln offers
a complimentary roadside assistance program. This program is separate from the New Vehicle
Limited Warranty. The service is available: 24 hours, seven days a week for the Basic Warranty
period (Canada) or New Vehicle Limited Warranty period (U.S.) of four years or 50,000 miles
(80,000 km). Roadside assistance will cover:
Roadside Assistance Centers
Country Phone Number
United States (800) 521-4140
Canada (800) 665-2006
For complete details on any roadside assistance concern, see the Roadside Emergencies chapter,
or the Customer Assistance chapter in your Owner’s Guide.
A
B
C
D
E
F
G
C
B
A
G
All information contained in the Lincoln Quick Reference Guide was accurate at
the time of duplication. We reserve the right to change features, operation and/or
functionality of any vehicle specification at any time. Your Lincoln dealer is the best
source for the most current information.
For detailed operating and safety information, please consult your Owner’s Guide.
The steering wheel controls are located on
the right-hand side of the steering wheel.
This control is located on the
driver’s door trim panel and
can be operated at any
time except when your
perimeter alarm system
is armed.
You may also open your trunk using your key
fob or the optional keyless entry system.
Press the control to open the trunk. If your
vehicle is equipped with a power trunk, press
the button again to close the trunk. You can
render the switch inoperable by locking the
button with your master key.
To close the trunk, gently push the trunk down
until you feel it latch. The power down latch will
then complete the full closing of the trunk. Do
not "slam" your trunk or force it downward.
D
C
B
A
D
D
C A
B
*F6W1J19G217AB*
CAUTION: DO NOT USE CD WITH ADHESIVE LABEL*
* CDs with adhesive labels and irregularly shaped CDs may get stuck in the CD player. Homemade CDs
should be identified with permanent felt tip marker rather than adhesive labels.
2
0
0
7
M
O
D
E
L
T
O
W
N
C
A
R
Q
U
IC
K
R
E
F
E
R
E
N
C
E
G
U
ID
E
quick reference guide
2 0 0 7 M O D E L TOW N C A R
B
A
■ Changing a flat tire ■ Jump-starts ■ Limited fuel delivery
■ Lockout assistance ■ Towing of your vehicle ■ Winch out
