LightSpeed Technologies CS-Q - Manual

Two CS-Q ™ wall speakers are ideal for
classrooms of up to 1200 square feet
with 8 to 12 foot ceilings.
13.0”
3.
54
”
• New Curved Design
• Two Speakers Fill Entire Room
• Elegant Cabinet Styling
Protected by Steel Mesh
• Horizontal or Vertical Mount
• Delivers a rich, full sound
In classrooms where recessed ceiling speakers are not practical,
the CS-Q
™ wall speaker is an excellent alternative. Lightweight,
sturdy and easy to install, these speakers deliver superb full-
range sound with optimum clarity.
Two CS-Q ™ wall speakers and a LightSPEED Classroom Amplifica-
tion System are all that is needed to guarantee that everyone
hears the same great audio quality throughout the classroom.
CS-Q ™
wall speaker specifications
LightSPEED Technologies
www.lightspeed-tek.com
800.732.8999
Speaker Type Twin-cone
Speaker Cone Size 6.5-inch
Frequency Response 110 Hz –20 kHz ±6 dB
Impedance 8Ω
Power Handling 10 W
SPL @ 1w/1m 94 dB
Dimensions (L x H x D inches) 13 x 9.45 x 3.54
Weight 1.56 lbs.
profile room coverage overview
CS-Q
™ wall speaker
imagine…
i
Top View of Room
Covers up to 1200 sq. ft.
(Example: 30 ft. x 40 ft.)
Side View
Front View
9.45
”
13.0”
