LightSpeed Technologies Wall Speaker - Manual

Front View
Description NXT™ Distributed Mode Panel
Panel Size 16.25” x 8.25”
Frequency Response 100 Hz–20 kHz
Impedance 8 Ω
Power Handling 15 W
SPL @ 1w/1m 96 dB
Dimensions (L x H x D inches) 18.25 x 10.25 x 1.5
Weight 2.2 lbs.
flat panel wall speaker
NXQ
™ flat-panel wall speaker
• A single NXQ loudspeaker,
wall mounted in a relatively
square room, will cover up to
1200 square feet.
• Dual NXQ loud speakers, wall
mounted in a long rectangular
room, will cover up to 2300
square feet, unless the room is
more than 40 feet wide.
The NXQ ™ flat panel wall
speaker is specifically designed
for use in small to medium size
classrooms. When the NX-Q is
positioned properly, its projected
sound covers the room uniformly.
NXT technology operates on the
principle of bending wave physics.
Exciters mounted to the back of
the panel produce modal or reso-
nant vibrations across the entire
panel surface.
NXT ™ technology produces a sound
source that has a much flatter
frequency response and more
uniform sound distribution than
conventional loudspeakers.
This new sound projection technol-
ogy is ideally suited for classroom
amplification. This is because
low-frequency sounds that can
mask critical speech components
are greatly reduced—resulting in
superior speech intelligibility.
The NXQ is ideally suited for
classrooms with ceilings that are
9–12 ft. It is employed in the
following configurations:
LightSPEED Technologies
800.732.8999
www.lightspeed-tek.com
imagine…
i
Covers up to 1200 sq. ft.
(Example: 30 ft. x 40 ft.)
10.25”
18.25”
Top View of Room
profile room coverage overview
NXQ ™
