Back panel, Side panels, Back panel side panels – Linksys SD2005 User Manual
Page 8
5-Port and 8-Port 10/100/1000 Ggabt Swtches
Chapter 1: Product Overvew
Back Panel
The Ethernet network ports are located on the back panel of
the Switch . All ports are auto-negotiating and have automatic
MDI/MDI-X crossover detection .
Back Panel of the 5-Port Switch
1- These ports (1, 2, 3, 4) connect the Switch to network
devices, such as computers .
Side Panels
The power port and security slot are located on the side panels of the
Switch .
Side Panel with Power Port
(power) The power port is where you will connect the power
adapter .
