Lindy 70584 User Manual
Page 3
PAGE 3
u
Pin Assignments
Serial 9 Pin male connector pin assignments:
Serial 9 Pin male connector:
Pin Signal Pin Signal Pin Signal Pin
Signal
1 CD 4 DTR 6 DSR 8
CTS
2 RD 5
GROUND
7 RTS 9 RI
3 TD
u
Technical Specification
Compatibility: PCI 32Bit card for 486/586/Pentium/Pentium-II/
P-III/C5/K6
Operating system: WIN 9.x/ME/NT/2000/XP, LINUX, DOS
Chips: 1 x SUN1889
Connections: 1 x DB 9 m connector serial
PCB: 2 Layer / 120 x 51 mm
