Revision Comments Part Description Part No. Ref.
(S/N 239291-) TUBE NYLON 1/4OD X 062WL 990-109R 32.
(S/N 239291-) GREASE ZERK 1/8NPT 45-DEG 800-193C 33.
(S/N 239291-) FTG TUBE,CONNECTOR 1/8 MNPT 800-157C 34.
NUT LOCK 3/4-16 NYLOC COLLAR 803-114C 35.
1/4 SQ. KEY X 7/8 LG 172-242D 36.
WASHER FLAT 3/4 HARD ASTMF436 804-093C 37.
AT2560, B-GROOVE PULLEY 5 O.D. 808-075C 38.
AT2572 B-GROOVE DRIVE PULLEY 6 O.D. 808-127C 38.
BEARING 6206 W/ METAL SHIELD 822-161C 39.
(S/N 329661+) BLADE HUB - MACH 310-224D 40.
(S/N 239292 <-> 329660) REP BY 310-348S 310-361D 41.
BEARING 206 822-006C 42.
BLADE HUB - 7/8 310-300D 43.
(S/N 239292+) CW TG SPINDLE HUB ASSY 5" PULL 310-248S 44.
(S/N 239292+) AT2572 CW TG SPINDLE HUB ASSY 6" PULL 310-249S 44.
(S/N 239292+) GREASE ZERK STRAIGHT 1/4-28 800-001C 45.
(S/N 239292+) BLADE HUB MACHINED TOP GREASE 310-457D 46.
Rev. 2 not compat. w/Rev. 1 (S/N 329661+) BLADE SPINDLE SHAFT CW TG 310-630D 47.
Rev. 1 (S/N 239292 <-> 329660) RPBY 310-349S 310-454D 47.
3 CW Blades per Kit 60" MOWER BLADE KIT, LOW LIFT 310-466A 48.
3 CW Blades per Kit 60" MOWER BLADE KIT, MED. LIFT 310-467A 48.
3 CW Blades per Kit 60" MOWER BLADE KIT, HIGH LIFT 310-468A 48.
3 CW Blades per Kit 60" MOWER BLADE KIT, MULCH 310-469A 48.
3 CW Blades per Kit 72" MOWER BLADE KIT, LOW LIFT 310-470A 48.
3 CW Blades per Kit 72" MOWER BLADE KIT, MED. LIFT 310-471A 48.
3 CW Blades per Kit 72" MOWER BLADE KIT, HIGH LIFT 310-472A 48.
3 CW Blades per Kit 72" MOWER BLADE KIT, MULCH 310-473A 48.
30 AT2560, AT2572, (AT2584 See AT2684), AT2660, AT2672, AT2684 & AT3590 Air Tunnel Grooming Mower 310-002P 04/22/13
Table of Contents Part Number Index
Land Pride Section 3: Drive
AT25 SERIES
Belt Drive (S/N 212181+) (continued)
Applies to AT2560, AT2572
