TVM 3077 & TVM 5130
VERTI - CUTTER
INDEX
SECTION DESCRIPTION SECTION
Mainframe and Related Parts 1
Guards 2
Drives, Gearboxes, Belts, Driveshafts 3
Wheels, Axles, Hubs 4
Hydraulics 5
Mowing Units 6
Decals 7
PART DESCRIPTION PAGE
Belt Idler 3-9
Compensator, Single 1-5
Dual 1-6
Cutter Head, TVM 3077 6-2, 6-3
Cutter Head, TVM 5130 6-4, 6-5
Adjusting Wheel 6-1
Decals 7-1, 7-2
Driveshaft, C.V. 3-5
Front Jackshaft 3-6
Rear Jackshaft, TVM 5130 3-7
Rear Jackshaft, TVM 3077 3-8
Gearbox and Sheaves, TVM 5130 3-1, 3-2
TVM 3077 3-3, 3-4
Guards, Primary 2-1
V-Belt, TVM 5130 2-2
V-Belt, TVM 3077 2-3
Hydraulic System, TVM 5130 5-1
TVM 3077 5-2
Lift Assembly TVM 5130 1-2
TVM 3077 1-4
Mainframe TVM 3077 1-1
TVM 5130 1-3
Wheel, Axle, Hub Assembly 4-1
(Note HHCS = Hex Head Cap Screw)
