4
Connections Signal Box
SYSTEM
Digital sound
input/output
Infrared
signal
Infrared Link
RC5/RC6
Antenna socket
PIP Tuner
Antenna socket
VHF/UHF/cable
Euro-AV-
socket 3
Euro-AV-
socket 2 Connection for TFT-LCD
monitor
VGA-
input
✳✳Connections
for active
speakers
Connection
Speaker system
Euro-AV-
socket 1
Connection for
Loewe Online Box
RC5/
RC6 IR-
LINK
SUB
SERVICE VGA DISPLAY PIP UHF/VHF
AV 3
(RGB/YUV)
AV 2
(RGB)
AUDIO
IN 1
DVI
AV 1
COM DIGITAL TV
SAT
A/D
SAT
COMPONENT
IN
TVO
C R
L
S
U
R 1
IN
2
DIGITAL
AUDIO
IN 3
R
L
R
L
R
L
AUDIO
OUT
120-240V~
50/60 Hz
OUT
AUDIO
IN 2
Socket for
power cable
✳ Satellite-
antenna socket
analogue/digital
✳ Satellite
antenna socket
analogue
Y
CR/
PR
CB/
PB
✳COM Digital TV
V24
Sound input
analogue
Digital Video
interface input
Sound input
TV Active
Component
Video/Audio-
Inputs
Sound output
Left / Right
* Only with upgrade "Digital-TV upgrade kit 2 Sat/Twin-Sat CI" or CIP
** Only with upgrade with Dolby Digital (AC3)
Note: For optimum picture resolution use the "Digital Visual Interface Input DVI"
Only connecting cables less than 2 meters long.
