Publication E10.11
www.lincolnelectric.com
A CLOSER LOOK
SYSTEM DIAGRAMS
Backward compatibility is supported
to ensure existing robotic cells can
be integrated with Power Wave ® i400
(shown here is a Power Wave ®
F355i replacement).
Flexible solution for integrated or
separated installations. The system
accommodates to your needs.
Dual Arm System
ArcLink ® XT
Ethernet
Connection
ArcLink ®
Connector
Voltage
Sense
Connector
Wire
Feeder
Connector
Devicenet
Connector
Circuit Breaker
(15 Amp)
ArcLink ® XT
Ethernet
Connection
ArcLink ®
Connector
Voltage
Sense
Connector
Wire
Feeder
Connector
Devicenet
Connector
Circuit Breaker
(15 Amp)
ArcLink ® XT
Ethernet
Connection
ArcLink ®
Connector
Voltage
Sense
Connector
Wire
Feeder
Connector
Devicenet
Connector
Circuit Breaker
(15 Amp)
FANUC Robotics R-30iA
“a-cabinet” Controller
with Integrated Op Box
ArcLink ® XT
Ethernet Cable
Power Wave ® i400
K2669-1
AutoDrive™ 4R90
K2685-2
Electrode
Connection
ARC Mate™ 1XXiC
Air
Gas
Wire Feeder
Power Wave ®
i400
K2669-1
FANUC Robotics R-30iA
“a-cabinet” Controller
with Integrated Op Box
(Master)
FANUC Robotics R-30iA
“a-cabinet” Controller
with Integrated Op Box
(Slave)
ArcLink ® XT
Control Cable
Power Wave ®
i400
K2669-1
ARC Mate™ 1XXiC (Slave)
ARC Mate™
1XXiC (Master)
AutoDrive™ 4R90
K2685-2
AutoDrive™
4R90
K2685-2
Electrode
Connection
Air
Gas
Wire Feeder
ARC Mate™ 1XXiBe Air
Gas
Wire Feeder
Work
Piece
Work
Piece
Work
Piece
* Electrode
Cable (+)
* Electrode
Cable (+) Work
Piece
*Work
Cable (+)
*Work
Cable (+)
* Electrode
Cable (+)
K2163-xx or
K1842-xx
* Work Cable (+)
K2163-xx or
K1842-xx
Wire Feeder
Control Cable
K1785-xx
Wire Feeder
Control Cable
K1785-xx
Wire Feeder
Control Cable
K1785-xx
Air
Gas
Wire Feeder
Electrode
Connection
ArcLink ®
Control Cable
K1543-xx
Optional Work
Sense Lead (21)
Optional Work
Sense Lead (21)
Optional Work
Sense Lead (21)
ArcLink ® XT
Ethernet cable
(Internal)
* Work Cable (+)
K2163-xx or
K1842-xx
Wire Feeder
Control Cable
K1785-xx
Optional Work
Sense Lead (21)
* Electrode
Cable (+)
K2163-xx or
K1842-xx
Power Wave ® i400
K2669-1
FANUC Robotics
R-J3iB Controller
Robotic
Torch
18” Adaper Cable
K1785-2
Power Feed 10R
K1780-2
