B-5 OPERATION B-5
EAGLE™ 10,000 PLUS
ARC GOUGING
The EAGLE™ 10,000 Plus can be used for limited arc
gouging.
Set the Range switch to adjust output current to the
desired level for the gouging electrode being used
according to the ratings in the following table:
SUMMARY OF WELDING PROCESSES
CONTROL ELECTRODE
CABLE IDLE WHEN NOT TO START
PROCESS USED MODE WELDING WELDING
ELECTRODE SETTING CURRENT RANGE (DC, electrode positive)
1/8 30 - 60 Amps
5/32 90 - 150 Amps
3/16 150 - 250 Amps
STICK No AUTO Hot Touch electrode to work.
Welding starts immediately
And engine goes to high
Idle.
TIG, TIG MODULE WITH Yes HIGH Cold Press Amptrol,
WITH CONTACTOR KIT Contactor closes,
CONTROL CABLE, & Welding starts immediately.
AMPTROL
