Efficiency
+
®
Boiler Dimensions & Specifications
Venting Options
AMP DRAW DATA
150,000 thru 300,000 Btu Models
FIRING
CONTROLS
F-9
(Single Stage)
M-9
(Two Stage)
FAN
1.15
1.15
PUMP
AMPS
100 150-300
2.1 5.8
2.1 5.8
VALVE/
CON TROLS
3.97
4.15
MAXIMUM
TOTAL AMPS
@ 120 VAC
5.12
5.30
MODEL NO.
EB 150-200
EB 250-300
DIM “A”
9-1/8”
9-5/8”
DIM “B”
8-7/8”
9-3/8”
DIM “C”
7-1/8”
7-5/8”
DIM
“D”
7-3/8”
7-3/4”
Horizontal Direct Vent Inlet and Outlet Cap
DIM
“E”
4-3/8”
4-3/8”
Conventional
Efficiency+ DirectAire
Direct Vent Vertical
Direct Vent Horizontal
Outdoor
Efficiency+ Boiler
Dimensions & Spec i fi ca tions
Input
Heating
Net
Model
Max
AFUE Capacity I=B=R
Gas
Vent
Shipping
Number
MBH
%
MBH
MBH
B
D
E
G
Conn.
Size
Weight
EBN150
150
83.2
129
112
19-3/4”
16”
7-1/4”
11-3/4”
3/4”
5”
245
EBN200
200
83.1
170
148
23-3/4”
20”
9-1/4”
11-3/4”
3/4”
5”
265
EBN250
250
83.2
218
190
27-1/2”
23-3/4”
11”
11-3/4”
3/4”
6”
290
EBN300
300
84.0
252
219
31-1/4”
27-1/2”
13”
11-3/4”
3/4”
6”
310
Notes: Change ‘N’ to ‘L’ to denote L.P. gas models
Electrical Requirements: 120 VAC / 2 AMP
Water connections are 1-1/2” NPT
Net ratings based on piping and pick-up allowance of 1.15
Performance data based on manufacturer test results.
