Lincoln Electric LN-8 SVM132-A User Manual
Ln-8 semiautomatic wire feeder, Service manual svm132-a
LN-8 SEMIAUTOMATIC WIRE FEEDER
SERVICE MANUAL
SVM132-A
May, 2002
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However, your
overall safety can be increased by
proper installation ... and thought-
ful operation on your part. DO
NOT INSTALL, OPERATE OR
REPAIR THIS EQUIPMENT
WITHOUT READING THIS
MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED
THROUGHOUT.
And, most
importantly, think before you act
and be careful.
For use with code numbers: 9963, 9964
