Page 10
(4) VS (Vertical Shift) adjustment:
Adjust so that the geometric vertical center line is in accord
with vertical center line of CPT.
(5) HS(Horizontal Shift) adjustment:
Adjust so that the geometric horizontal center line is in
accord with horizontal center line of CPT.
8.OPTION Adjustment
8-1. Preparation for Adjustment
1) This option adjustment decides function in accordance with
model. Press IN-START button on SVC communicator,
then adjust the option at OPTION1 mode.
2) Mark the option adjustment data like [111,111,111,111] in
BOM.
8-2. Adjustment Method
OPTION data input
1) Function : YES, No function : NO
2) Select each OPTION function by the CH Up/Down
button and then set up each OPTION(yes or no) by the
VOL Up/Down button.
8-3. OPTION 1
8-4. OPTION2 Function
8-5. OPTION3 Function
- 10 -
Menu
VS
VA
VL
SC
HS
-512~511
-512~511
-512~511
-512~511
32~2047
150
-12
140
6
100
140
-12
140
6
123
Variable range
N50Hz(PAL)
FLAT 21Ó
N60Hz(NTSC)
FLAT 21Ó
INCH
SYS
SOUND
CH+AU
Option
Code
0
1
2
3
4
5
6
7
0
1
2
3
0
1
2
3
0
1
Function
21A
21B
21C
29F/25F
28WF/32WF
28N
34F
29N/25N
BG/I/DK
BG/I/DK/L
BG/I/DK/M
BG/L
RF STEREO
AV STEREO
MONO
MONO DUAL
Using
Not using
