4-50 MAX 6000/3000 Network Configuration Guide
Configuring Individual WAN Connections
Configuring MP, MP+ and BACP connections
Example of a MP connection without BACP
To configure an MP connection without BACP:
1 Open the Ethernet > Answer profile.
2 Enable PPP and MP encapsulation and specify the appropriate routing, bridging, and
authentication values. For example:
Ethernet
Answer
Encaps
PPP=Yes
MP=Yes
PPP Options
Route IP=Yes
Route IPX=Yes
Bridge=Yes
Recv Auth=Either
3 Exit the profile and, at the exit prompt, select the exit and accept option.
4 Open a Connection profile, specify the name of the remote device, and activate the profile.
For example:
Ethernet
Connections
fred
Station=fred
Active=Yes
5 Select MP encapsulation, and open the Encaps Options subprofile.
6 Configure PPP authentication. For example:
Encaps=MP
Encaps Options
Send Auth=PAP
Send PW=remotepw
Aux Send PW=N/A
Recv PW=localpw
7 Set the base channel count and maximum channel count. For example, to use two channels
for this call:
Base Ch Count=2
Max Ch Count=2
Note: Both sides of the connection should specify the same number of channels.
8 Exit the profile and, at the exit prompt, select the exit and accept option.
Ascend-Maximum-Chan
nels (235) Maximum number of channels available to a multilink PPP
connection. In this release, MP does not make use this value.
However, it’s value does apply to MP+ connections.
Note: If a RADIUS profile does not specify
Ascend-Maximum-Channels, the default value of 1 prevents the
client from establishing a multichannel call.
Attribute Value
