STATOR/ROTOR REMOVAL AND REPLACEMENT
(continued)
18. Install the output choke. Refer to the
topic "OUTPUT CHOKE REMOVAL AND
REPLACEMENT" in this section of the
manual.
19. Install the output rectifier bridge. Refer to
the topic "OUTPUT RECTIFIER BRIDGE
REMOVAL AND REPLACEMENT" in this
section of the manual.
20. Replace the control panel and tighten the
6 sheet metal screws.
22. Replace the top cover to the control box
and tighten the 8 sheet metal screws.
23. Conduct the "RETEST AFTER REPAIR"
procedure, the following topic in this sec-
tion of the manual.
TROUBLESHOOTING & REPAIR
F-58
F-58
WELDANPOWER 125
