the test. Depress the spring-loaded brush-
es into the holder and slip a suitable non-
metallic, fairly stiff retainer through the slots
at the top and bottom of the holder. A
cable tie works well; see Figure F.3. This
will hold the brushes up so that you can
easily install the holder.

10. Slip the holder into position in the genera-

tor end bracket. Be careful not to loosen
the 2 attached wires.

11. Reinstall and tighten the 2 screws with the

1/4” nut driver.

12. Slowly remove the non-metallic retainer

from the brush holder and let the brushes
snap back against the slip rings.

13. Snap the brush holder cover back into

position.
