Liebherr RO500 - Manual (Page 8)

Activated charcoal filter
Adjustable-height feet
Model plate
Operating and control
elements
Door rack
Shelves
Adjustable door rack
Ventilation grille
8
I
NSTALLATION
Installation
- Figure 2
The electrical outlet should be easily accessible
and not directly behind the appliance.
IMPORTANT
Do not block the ventilation grille (Figure 2).
Figure 2
The appliance is adapted with a door opening lim-
iter. The maximum opening angle is 100°.
Dimensions
- Figure 1
Figure 1
To level the appliance, adjust the height of the feet
with the open-ended wrench supplied.
Description of Appliance and Equipment
- Figure 3
Figure 3
