Lenovo 41N5631 - Manual (Page 20)

CD-RW 20x CAV
CD-DA (DAE) 10x CAV
Write speeds for Configuration 2
Media
Max speed with USB Standard Bus
Power Disc spin method
DVD-R 8x ZCLV
DVD-R DL 4x ZCLV
DVD-RW 6x ZCLV
DVD+R 8x ZCLV
DVD+R DL 4x ZCLV
DVD+RW 8x ZCLV
DVD-RAM (4.7/9.4) 5x ZCLV
CD-R 24x ZCLV
CD-RW 24x ZCLV
To connect the Lenovo USB 2.0 Super Multi-Burner Drive (With LightScribe) to your system using
standard USB bus power, do the following:
1. Turn on your computer.
2. Using the USB cable, insert the cable plugs 1 into the USB connector of the drive.
3. Plug the USB connector 2 into the USB port of your computer.
Figure 1-2. Configuration 2: standard USB bus power configuration
1-8 Lenovo USB 2.0 Super Multi-Burner Drive (With LightScribe) User’s Guide
