Listen Technologies LA-201 - Manual (Page 2)

Don't miss a single sound.
LR-600 Wireless Speaker
Close up of back panel Hand held soundfield!
Close up of top
control panel
updated 10.21.05
3
2
9
2
8
3
7
6
1
4
8
7
2
5
3 6 4
*
1
LR-600 Features
1. Top mounted channel selection and volume controls for easy access.
2. Operates on 15VAC power supply (LA-201, included), 12VDC, or internal eight AA battery pack. Can also be used
with Listen NiMH Rechargeable AA Batteries (LA-362).*
3. Unbalanced auxiliary phono input and output ports.
4. Adjustable handle/mounting bracket. Includes leatherette wrap for hand held use. Leatherette wrap may be removed
to mount unit on a wall or ceiling (screws and hollow wall anchors included) or on a microphone stand (16mm nut
included). Handle angle can be adjusted 360°.
5. 15/10 Watt (peak/RMS) continuous power with 4 Ohm load, 2-way speaker. Can also drive a separate LA-316
Expansion Speaker.
6. When enabled, SQ™ technology provides highest audio quality available in its product category. SQ can be disabled
for compatibility with other assistive listening equipment.
7. LR-600 works with Listen’s LT-800 Stationary or LT-700 Portable FM Transmitter; it is also compatible with all other
major ALS transmitters.
8. Backlit Look&Listen™ LCD Display indicates channel selected as well as electronic lock status. UP, DOWN, and
SEEK buttons tune to 57 channels. Unit can be programmed to show only the channels in use.
9. Adjustable three-band equalizer.
10. Internal antenna. For longer range applications, add a Listen 90 Degree Helical or other Listen remote antenna
(external antennas sold separately).
*batteries sold separately.
