Lennox Hearth ELITE EBVI30US User Manual
Page 17
17
REPLACEMENT PARTS LIST
Gas Controls
Item #
Part/Cat. No.
Description
Where Used
1
67L70
Pilot Assembly, NG/LP
EBVI5 & EBVI30
67L68
Pilot Tube
EBVI5 & EBVI30
3
67L67
Thermocouple
EBVI5 & EBVI30
4
60J79
Thermopile (pilot generator)
EBVI5 & EBVI30
5a
10K86
Piezo Igniter
EBVI5
5b
4M89
Piezo Igniter
EBVI30
6
67L87
Electrode Cable (piezo igniter wire w/ electrode)
EBVI5 & EBVI30
7a
H1657
Gas Valve, NG – SIT
EBVI5
7b
H6196
Gas Valve, NG – Honeywell
EBVI30
Misc. Gas Components
8
H1161
Burner Assembly NG/LP
EBVI5 & EBVI30
H1576
Conversion Kit, NG to LP (GCKNL-E5I)
EBVI5
H090
Conversion Kit, NG to LP (GCKNL-E30I)
EBVI30
9
93L3
Connector-Flex Gas
EBVI5 & EBVI30
10a
1L79
Orifice, Burner, NG (#41)
EBVI5
10a
4M10
Orifice, Burner, NG (#37)
EBVI30
10b
39L10
Orifice, Burner, LP (#53)
EBVI5
10b
1L01
Orifice, Burner, LP (.065”)
EBVI30
Miscellaneous Parts
1
H1585
Door Kit, Complete
EBVI5
1
H095
Door Kit, Complete
EBVI30
13
H098
Grate Assembly
EBVI5 & EBVI30
69L1
Latch, Door
EBVI5 & EBVI30
14a
H1138
Switch, Vent Spill Switch
EBVI5 & EBVI30
15
7K30
Switch, Off/on
EBVI5 & EBVI30
Log Set
16
88L53
FGE Glowing Embers
EBVI5 & EBVI30
17
H635
Log Set, 7 pc.
EBVI5 & EBVI30
18
H3696
Vermiculite, Bag
EBVI5 & EBVI30
Room Air Blower System
19
H1391
Blower Assembly, 7”
(H118)
EBVI5
19
H1141
Blower Assembly, 9”
EBVI30
0
H1157
Power Cord
EBVI5 & EBVI30
1a
H190
Rheostat (knob included)
EBVI5 & EBVI30
1b
57
Knob, Rheostat
EBVI5 & EBVI30
14b
13M3
Switch, Temp. Control (TOD)
EBVI5 & EBVI30
