Lincoln Electric SVM143-A User Manual
Dh-10 heads & controls, Operator’s manual svm143-a, Boom mount or bench models

DH-10 Heads & Controls
Boom Mount or Bench Models
OPERATOR’S MANUAL
SVM143-A
March, 1999
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However, your
overall safety can be increased by
proper installation ... and thought-
ful operation on your part. DO
NOT INSTALL, OPERATE OR
REPAIR THIS EQUIPMENT
W I T H O U T R E A D I N G T H I S
MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED
T H R O U G H O U T . And, most
importantly, think before you act
and be careful.
For use with: DH-10 Control - Boom Mount Code 10357
DH-10 Drive - Boom Mount Codes 10358 (Std.), 10359 (Hi/Std.)
DH-10 Boom Package Codes 10380, 10495, 10496 (Std.), and 10517, 10518, 10519 (Hi/Std.)
Standard - Single Head Drive Codes 10190, 10191
DH-10 Feeder Double Head - Bench Model Codes 10360 (Std.), 10361 (Hi/Std.)
