Logitek Standard Elec. Cable Manufacturing C/A210 - Manual (Page 7)

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Model F (1) G H J(2) M
C/A210 18”
450mm
12-1/4”
311mm
19”
483mm
4-1/2”
114mm
42-1/8”
1070mm
C/A210 w/
mantel and/or
side shields u
18”
450mm
12-1/4”
311mm
19”
483mm
4-1/2”
114mm
34-1/8”
867mm
* Reduced clearances may be available for A, B, C and D
dimensions per NFPA 211 - latest edition, Standard for
Chimneys, Fireplaces, Vents, and Solid Fuel-Burning Ap-
pliances (in Canada CSA B365 - latest edition). See section
on “Reduction of Appliance Clearance with Specified Forms
of Protection.”
** Side view of optional mantel deflector shown.
(1)Hearth extension reductions: 2” (51mm) reduction for 2”
(51mm) raised hearth. (USA) 16” minimum hearth exten-
sion on all stoves as measured from the door opening of the
unit. (Canada) 18”(450mm) minimum hearth extension on
all stoves as measured from the door opening of the unit.
Minimum distance of floor protection to the side = 8” (200mm).
This is measured from the sides of the door opening in the
USA and from the sides of the insert in Canada.
(2) J = Maximum lintel depth without flue offset or smoke
deflector.
h
earth
P
roteCtion
The hearth and/or floor protection must be a thermally rated
non-combustible hearth/floor protector meeting or exceeding
a thermal rating of k=.84 or equivalent with a listed thickness
of 3/8" (9.5mm) minimum in USA (3/4" - 19mm minimum in
Canada). The covering must extend 18” (450mm) in front
of the heater and 8” (200mm) to either side (measured from
door opening in the USA and measured from the side of the
unit in Canada).
Notes:
• Facing material that projects more than 3/4” (19mm) from
the wall is considered a mantel or side wall.
• MINIMUM FIREPLACE OPENING 19-1/2” (495mm) High x
26” (660mm) Wide
Top Facing / Trim
Side Facing Materia
l
SIDE WALL
C
E (USA)
D
B
A
COMBUSTIBLE MANTEL
Insert
Maximum Mantel Depth = 9” (229 mm)
Hearth Protection
E (Canada)
M 6-1/2”
165mm
F
**
J
G
H
Mantel
Hearth Protection
Trim
Model *A *B *C *D E(1)
C/A210 USA-24”
CAN-813mm
USA -18”
CAN-660mm
18”
450mm
15”
381mm
USA-8"
CAN-200mm
C/A210 w/
mantel
and/or side
shields u
USA-16”
CAN-813mm
USA -10”
CAN-660mm
18”
450mm
USA-8”
381mm
USA-8"
CAN-200mm
r
equireD
C
learanCes
WARNING: BE ABSOLUTELY SURE THE DISTANCE BE-
TWEEN THE HEATER AND THE SURFACE OF ANY COM-
BUSTIBLE CONSTRUCTION IS NOT LESS THAN SHOWN
ON THIS PAGE.
9”
229mm
Top View
Figure 4
Figure 5
Figure 6
23”
584mm
25-1/2”
648mm
