Landice 8700 User Manual
Version m/c.1
1
111 Canfield Avenue
•
Randolph, New Jersey 07869
•
1-800-LANDICE
•
FAX 973-927-
0630
8700-Series
Home and Commercial Treadmill
Diagnostic and Service Manual
2001
This guide covers all 8700 series treadmills manufactured from
1993 – 2000.
HOME TREADMILLS – 8700 SPRINT 1-4 / PRG / SST
NOTE: Early HOME treadmills listed as: 8700R & 8700P are the same as the LTD models.
The only difference was the warranty coverage.
LTD / 110V UNITS – 8700R (
REGILAR NO PROGRAMS
) / P (
WITH PROGRAMS
) / PT1 / PT2
CLUB / 220V UNITS – 8700R (
REGILAR NO PROGRAMS
) / P (
WITH PROGRAMS
) / PT1 / PT2
Version M/C.1
For Technical Service Call 1-(800)-LANDICE
