Page 16
150 LBS. WEIGHT STACK ASSEMBLY - 7464701 ________________________________________
MTSLE LEG EXTENSION
1
2
3
4
8
6
5
7
9
ITEM NO. QTY. PART NO. DESCRIPTION
1 14 7353701 ASSY, 10 LB PLATE
2 1 7464801 BAYONET, MTS, 15 HOLE
3 1 3236001 BUSHING, SPRING PIN
4 1 7356501 PLUG, LANYARD ATTACHMENT
5 1 7353001 ASSY, SELECTOR PIN
6 1 7434401 HEAD PLATE, MTS
7 2 7338001 BUSHING, HEADPLATE
8 1 7523601 CRIMP, CABLE
9 2 7767601 BUMPER, PS INCREMENT WT
Weight Stack Labels
PART NO. DESCRIPTION
8072201 LABEL, MTS, WGHT STK, 150 LBS
8072101 LABEL, MTS, WGHT STK, 80 KG
