Getting Started
Cisco Wireless IP Phone 7920 for Cisco CallManager 11
Figure 1-1 Installing and Removing the Battery
1 Locking catch—Press to release the battery.
2 Catches—Insert these into the slots near the
bottom of the phone at battery installation.
3 Metal contact—Match the contact on the
battery to the contact on the phone.
2 2
79675
1
3
