Line 6 DIGITAL WIRELESS XD-V75 - Manual (Page 30)

30
XD-V75 Digital Wireless System Specifications
System
Frequency Band 2.4GHz ISM Band
Compatible Channels 14
True Diversity Yes
Frequency Diversity Yes (2 Frequencies per channel)
Compander-Free Design Yes
Frequency Response THD % 10 Hz (-0.5 dB) - 20kHz (-2.5 dB)
0.03% typical
System Latency < 2.9 ms (audio input to output)
Operating Temp Range 1 – 50 degrees C
Construction
XD-V75 Receiver
THH12 & TBP12 Transmitters
Extruded aluminum chassis
Metal enclosures
Receiver
Receiver Gain Control 0 dB nominal; -18 to +12 dB range
RF Performance Monitoring Yes (via LCD screen and LED)
Scanning and Channel Management Yes (via LCD screen and function menu)
RF Signal Strength Indicators 5-Segment LED
Audio Level Meter (on Receiver) 5-Segment LED
Dynamic Filter Yes (selectable)
Squelch & Pad adjustments None required
Number of Receiver Antennas 2
Receiver Format 1/2 RU (with included rack-mount kit)
Receiver Power Requirements 9Vdc 500mA
Output Impedance XLR: 150 Ohms Balanced
1/4”: 1 kOhm Unbalanced
Sensitivity -95 dBm
Image Rejection 56 dB
Antenna Distribution A and B In & Out BNC Connectors
Antenna Impedance 50 Ohms
